GEP Universal Pre-wired Waterproof Mini Fuse Relay Panel Box Holder 80 AMP 12V
GEP Universal Pre-wired Waterproof Mini Fuse Relay Panel Box Holder 80 AMP 12V
Specifications
| Return Shipping Will Be Paid By | Buyer |
| Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| Manufacturer Part Number | FRH12-4F120R |
| Brand | 12VC |
Pre-Wired GEP Power Products 12 way sealed fuse and relay holder. Ideal for harsh environments and sub-panel applications. Also suitable for add-on panels for motorcycles, ATV’s, and utility vehicles. Accepts MINI fuses and ISO 280 components. Fully rebuildable and serviceable unit. Stainless steel anti-rotation mounting tab. Single wire 8 AWG input with 3 constant fused outputs and 1 fused 20 amp relay output. GXL automotive wire. Delphi terminals and wire seals. Compact panel rated for up to 80 amps maximum, 30 amps max per circuit. Wiring diagram included. Model: FRH12-4F120R - 3 fused constant outputs and 1 fused 20 amp relay output Includes: 8 AWG GXL input cable 3’ length18 AWG relay coil common 8’ length(1) 18 AWG relay trigger 8’ length(1) 14 AWG fused 20 amp relay output 8’ length(1) 14 AWG fused constant outputs 8’ length(2) 16 AWG fused constant outputs 8’ length(1) 20 amp Song Chuan ultra micro relay with coil resistor (14) Littelfuse Mini ATM fuses 2 each 5, 7.5, 10, 15, 20, 25, 30 amp Wire colors may vary. Panel dimensions not including mounting tab: 2.5”L x 1.5”W x 3” T Lifetime warranty on craftsmanship. Custom wiring available. Other pre-wired options can be found in the Pre-Wired Fuse Panel category.
